Anvore on-site PSA Nitrogen Generation System ·

Professional On-Site Nitrogen Generation System for Laboratory & Industrial

The Anvore AV-100LB PSA Nitrogen Generator is a complete, skid-mounted nitrogen generation system built on Pressure Swing Adsorption (PSA) technology. Compressed air is produced by the built-in oil-injected screw air compressor, stored in an air receiver tank, then purified through a multi-stage filtration system (oil, dust and water removal) and a refrigerated air dryer. The clean, dry compressed air enters the adsorption towers filled with carbon molecular sieve (CMS), where oxygen and nitrogen are separated. The resulting high-purity nitrogen is delivered to a buffer tank, continuously monitored by a purity analyzer and flow meter — off-spec gas is automatically vented, while qualified nitrogen is stored ready for production.

The AV-100LB provides true on-site nitrogen generation — eliminating the cost, safety risk and logistics of high-pressure gas cylinders, and delivering stable, on-demand nitrogen

Key Advantages

• Output pressure up to 0.7 MPa — fully meets the high-pressure gas source requirements of demanding applications.
• All-in-one plug-and-play design — built-in air compressor, refrigerated air dryer and filtration system; no extra equipment needed, just connect air and power.
• Mobile & stable — caster wheels with lock design ensure steady placement and easy movement between workstations.
• Real-time quality monitoring — built-in nitrogen purity analyzer and flow meter display purity and flow continuously for easy operation.
• Molecular sieve protection — specially designed compressed-air micro-oil adsorber removes residual oil traces with activated carbon, extending carbon molecular sieve life.
• Energy-efficient CMS selection — long-term cooperation with domestic and international molecular sieve suppliers; the most energy-saving sieve is selected according to your operating conditions.
• Stable supply pressure — the air receiver tank buffers the feed for the oxygen/nitrogen separation unit, reduces pressure fluctuation and airflow pulsation, improves purification performance and lowers failure rate.
• Consistent output quality — the nitrogen buffer tank equalizes the purity and pressure from the separation unit, ensuring stable flow, purity and pressure for downstream processes.

Features

Technical Specifications

System Structure & Working Principle

• Three-stage PSA nitrogen generation flow:
• Stage 1 · Compressed air supply — air compressor → refrigerated air dryer → air receiver tank
• Stage 2 · PSA adsorption separation — filtration → adsorption tower A/B (carbon molecular sieve) alternating between adsorption and regeneration
• Stage 3 · N₂ delivery & quality control — N₂ buffer tank → purity analyzer → flow meter → qualified nitrogen output

Applications

Why Choose Anvore
