Laboratory Closed Loop Organic Solvent Spray Dryer with Nitrogen Circulation
Loop sequence Atomized feed contacts heated nitrogen. Powder is separated and collected. The process gas passes through filtration and condensation;.
Compact nitrogen circulation spray drying for solvent based and oxidation sensitive laboratory samples
| Built for controlled solvent processing AV-OSSD6000 is a compact closed loop spray dryer for laboratory development with organic-solvent-bearing, toxic, harmful or oxidation-sensitive feeds. Nitrogen replaces process air and circulates through drying, filtration and condensation sections. Oxygen and pressure monitoring support controlled operation, while the condenser captures solvent from the circulating gas before reuse. Recommended use Best for formulation screening, small-batch material development and solvent-based feasibility trials. Process note Final solvent compatibility and operating conditions should be confirmed by a process-risk assessment. |
Six Key Advantages
PRINCIPLE AND TECHNICAL DATA
Loop sequence Atomized feed contacts heated nitrogen. Powder is separated and collected. The process gas passes through filtration and condensation; recovered solvent is collected, and dry nitrogen returns through the blower and heater.
| Feed solution | → | Two-fluid orcentrifugal atomizer | → | Heated nitrogen | → | Drying chamber | → | Powder separationand collection |
|---|---|---|---|---|---|---|---|---|
| ↓ | ||||||||
| Dry nitrogenreturns to heater | ← | Blower and heater | ← | Solvent collection | ← | Condenser | ← | Gas filtration |
Technical Specifications
- Specifications are based on the supplied source document and may change with configuration. Confirm utilities, materials of construction, solvent compatibility and compliance requirements before ordering.
| Parameter | Specification |
|---|---|
| Feed rate | 501500 mL/h(Max theoretical; Depends on solvent & solidcontent) |
| Inlet temperature | Ambient to 250°C; ±0.5°C |
| Outlet temperature | Ambient to 100°C; ±0.5°C |
| Condensation temperature | −15°C |
| Pipeline temperature | Ambient to 100°C; ±0.5°C |
| Atomization | Two-fluid nozzle |
| Oxygen measurement | 0–100%; resolution 0.1 |
| Feed interlock | Starts below 3% O₂ by default; setpoint adjustable |
| Pressure measurement | 0–100 kPa |
| Automatic relief | Above 0.02 MPa by default; setpoint adjustable |
| Airflow | 0–150 m³/h; variable-frequency control |
| Drying chamber | Ø20 × H40 cm |
| Filter recovery unit | Ø17 × H58 cm |
| Condenser | Ø17 × H88 cm |
| Overall dimensions | 106 × 95 × 108 cm L × W × H |
APPLICATIONS
- Suitable applications depend on feed chemistry, solvent properties, required powder characteristics and site risk controls.
| Pharmaceutical AP Is Solvent-based formulation and active-ingredient development. | Battery Materials Electrode, electrolyte and functional material research. |
|---|---|
| Fine Chemicals Controlled drying of specialty chemical intermediates. | Polymers and Resins Polymer, coating and resin process development. |
| Pigments and Dyes Colorant and dispersion powder development. | Advanced Materials Electronic, catalytic and functional powders. |
