Low Temperature Spray Drying Machine

The AVPWG-3000D low temperature spray dryer provides higher throughput for laboratory scale-up and small pilot trials. Its dehumidification system.

ModelAV-LT3000D

BrandANVORE

The AVPWG-3000D low temperature spray dryer provides higher throughput for laboratory scale-up and small pilot trials. Its dehumidification system reduces the moisture load of the drying air, supporting powder formation at lower process temperatures while helping retain the original characteristics of temperature-sensitive materials.

More capacity for heat-sensitive formulation development Up to 3,000 mL/h Two-fluid nozzle Low-temperature mode to 80°C High-temperature mode to 280°C Automatic humidity control and dehumidification

Key Advantages

Up to 3 L/h capacity A practical step up from bench-top testing for formulation screening and process optimization.	Low-temperature mode Dry heat-sensitive feeds from ambient temperature to 80°C under atmospheric pressure.
High-temperature option Use the same system for conventional spray drying up to 280°C when the formulation allows.	Two-fluid spray nozzle Interchangeable 316 stainless-steel nozzle sizes support atomization trials.
Controlled drying air Adjustable airflow, automatic humidity sensing, condensation and active dehumidification.	Repeatable operation Touch-screen control, digital feed and pressure settings, temperature recording and safety protection.

Working Principle

The system conditions the drying air to reduce its moisture load. The feed is atomized into fine droplets, which contact the controlled drying air for rapid moisture removal at a lower process temperature.
Operating concept: Automatic humidity sensing and dehumidification help maintain drying conditions. The integrated condenser recovers moisture, while the removable drying chamber and cyclone simplify cleaning.

1Filter air	→	2Condition and dehumidify air		→	3Atomize liquid feed		→	4Low-temperature drying
5Separate powder in cyclone		→	6Collect dry powder			→	7Condense moisture and control humidity

Technical Specifications

Parameter	Specification
Model	AVPWG-3000D
Feed capacity	Up to 3,000 mL/h
Drying chamber diameter	600 mm
Low-temperature mode	Ambient to 80°C; control accuracy ±0.5°C
High-temperature mode	Ambient to 280°C; control accuracy ±0.5°C
Outlet temperature	Ambient to 100°C; control accuracy ±0.5°C
Atomization	Two-fluid nozzle
Pressure adjustment	0-0.6 MPa
Airflow	0-420 m³/h
Heating power	4.0 kW
Automatic dehumidification power	2.0 kW × 2
Control interface	7-inch touch screen with communication port RS232
Construction	304 stainless-steel body and jacketed heating system
Safety protection	Leakage, voltage stabilization and overheat protection
Automatic energy-saving system	Included

Applications

Typical low-temperature spray drying applications include the following heat-sensitive and value-added materials.

Biological products Heat-sensitive cultures and biological formulations	Probiotics Liquid cultures and functional ingredients
Enzymes and proteins Research samples and active ingredients	Plant extracts Botanical extracts and natural ingredients
Food and beverages Fruit, vegetable and beverage powders	Specialty chemicals Laboratory and fine-chemical formulations
